• Steel planetary drive delivers high torque
• Protective shields for hydraulic & electrical components
• Solid hardened steel wheels with greasable manifold pins and secluded greased zerks
• 1 year limited warranty
Hydraulic Motor - (Must Choose Motor Type Before Adding To Cart) from 29-35GPM or 36-44GPM
Cutting Width Wheel Options (Must Choose Before Adding To Cart) from 2.5" Wide or 4.0" Wide
Hoses with couplers (Case Drain Line Required) and Control Box included
| Model | 18" Depth Wheel | 24" Depth Wheel |
|---|---|---|
| Dimensions (WxHxL) | ||
| Transport | 67" x 79" x 76" | 67" x 81" x 86" |
| Operating, guide arm down | 67" x 39½" x 119" | 67" x 44" x 132" |
| Operating, guide arm up | 67" x 49¾" x 77" | 67" x 58" x 89" |
| Maximum Cutting Depth | 18" | 24" |
| Side Shift (center to right) | 24" | 24" |
| Spoil Removal Path | 34" | 34" |
| Wheel Diameter | 48" | 60" |
| Number of Picks | 42 | 56 |
| Hydraulic Flow Requirement | 31-33 gpm | 35-39 gpm |
| Operating Pressure | 2500-3000 psi | 2500-3000 psi |
| Weight (without picks) | 1800 lbs | 2100 lbs |
