- Our Industrial Series High Flow Planers have a hydraulic flow range of 22-44 gpm
- Planetary drive delivers high torque
- High rear spoil clearance to prevent recirculation of material
- Protective shields for hydraulic & electrical components
- Solid hardened steel wheels with greasable manifold pins and secluded greased zerks
- (Includes Drum assembly & Deutsch - 14 pin electrical connector with joystick)
|
| Model | SP300 | HP400 | HP450 | HP600 | HP750 | HP1000 |
|---|---|---|---|---|---|---|
| Planing Width | 12.0" | 16.0" | 18.0" | 24.0" | 30.0" | 40.0" |
| Planing Depth | 0-5" | 0-5" | 0-5" | 0-5" | 0-5" | 0-5" |
| # of Carbide Picks | 37 | 43 | 45 | 57 | 69 | 89 |
| Weight | 1500 lbs | 2150 lbs | 2200 lbs | 2400 lbs | 2600 lbs | 3100 lbs |
| Hydraulic Requirements | standard | high-flow | high-flow | |||
| Hydraulic Flow Range | 12-22 gpm | 22-40 gpm | 22-40 gpm | |||
| Overall Width | 51.94" | 64.94" | 64.94" | |||
| Overall Height | 32.15" | 34.57" | 34.57" | |||
| Overall Length | 43.86" | 50.30" | 50.30" | |||
| Tilt | ±11° | ±8° | ±8° | |||
| Drum Diameter | 19.0" | 22.0" | 22.0" | |||
| Sideshift (to right) | 0" to 9" | -3" to 22" | -3" to 22" | |||
| Operating Pressure | 2500-3000 psi | 2500-3000 psi | 2500-3000 psi | |||
